3.5 bbl | Nano Jacketed Unitank

Free LTL Shipping

ASME Certified Jacketed Unitanks available upon request | pro@ssbrewtech.com


Cooling options for Ss Branded Glycol Chillers
Cooling options for Pressurized Glycol Loops on Commercial Chillers

      SKU: FV035T-01

      • Pro Construction: 3 mm inner wall, 2 mm dimpled glycol jacket, 1.5 mm outer wall
      • Lower cone and body glycol jacket
      • Lid cap includes combination 3" dry hop port and 17 PSI PRV
      • Blow off tube and sanitary pressure gauge
      • Zwickle-style sampling valve and analog thermometer
      • 1.5" TC rotatable racking arm with DIN nut, 1.5" lower dump port
      • Discrete cylinder and cone jackets allow for half batching
      • 1/2" NPT glycol inlet and outlet ports with internal jacket tie
      • 316 SS carbstone with valve
      • Cone-mounted sleeved RTD port with probe included
      • 4 MM lower stiffener plate with adjustable feet
    • 1bbl - 33" Wide x 57" Height
    • 2bbl - 35" Wide x 69" Height
    • 3.5bbl - 45" Wide x 80" Height
    • JACKETED UNITANK

      JACKETED UNITANK

      The Jacketed Unitank is designed and built alongside our line of larger Pro Unitanks, and includes all the features you'd expect on a professional level fermenter.

      The Jacketed Unitank is designed and built alongside our line of larger Pro Unitanks, and includes all the features you'd expect on a professional level fermenter.

      Available in 1 bbl, 2 bbl & 3.5 bbl

      Available in 1 bbl, 2 bbl & 3.5 bbl

      Engineering Better Beer

      Engineering Better Beer

      We set out to design our line of Jacketed Unitanks by taking the same robust material thicknesses, finishing standards, and glycol jacketing as our Pro Unitanks, then scale them down to popular pilot and nano brewery sizes.  It was also important that us that we borrow popular cues from our single wall Unitanks such as a lower stiffener plate, and square tube leg design.

      Finally, we carried over our popular zwickle sampling valve, DIN racking arm, sleeved thermowell port, and analog thermometer.  Then added a Pro carb stone along with a combination CIP and dry hoping port.  However, instead of incorporating a cumbersome off the shelf manway we decided to innovate on the familiar TC standard and develop our own proprietary TC lid and gasket system that prevents the gasket from inadvertently falling into the tank when installing and removing the lid cap.  The line of Jacketed Unitanks strikes the perfect balance of Pro performance in a smaller package.

      We set out to design our line of Jacketed Unitanks by taking the same robust material thicknesses, finishing standards, and glycol jacketing as our Pro Unitanks, then scale them down to popular pilot and nano brewery sizes.  It was also important that us that we borrow popular cues from our single wall Unitanks such as a lower stiffener plate, and square tube leg design.

      Finally, we carried over our popular zwickle sampling valve, DIN racking arm, sleeved thermowell port, and analog thermometer.  Then added a Pro carb stone along with a combination CIP and dry hoping port.  However, instead of incorporating a cumbersome off the shelf manway we decided to innovate on the familiar TC standard and develop our own proprietary TC lid and gasket system that prevents the gasket from inadvertently falling into the tank when installing and removing the lid cap.  The line of Jacketed Unitanks strikes the perfect balance of Pro performance in a smaller package.

      Features

      Features

      Pro Construction: 3 mm inner wall, 2 mm dimpled glycol jacket, 1.5 mm outer wall

      Cone and body glycol jackets

      Proprietary TC lid cap with TC gasket retention system

      Lid cap includes combination 3" dry hop port and PRV

      Blow off tube and sanitary pressure gauge

      Zwickle sampling valve and analog thermometer

      1.5" TC rotatable racking arm with DIN nut, 1.5" lower dump port (2in on 3.5 bbl tank)

      Discrete cylinder and cone jackets allow for half batching

      1/2" NPT glycol inlet and outlet ports with internal jacket tie

      316 SS carbstone with valve

      Cone mounted sleeved RTD port with probe included

      4 MM lower stiffener plate with adjustable feet

      Pro Construction: 3 mm inner wall, 2 mm dimpled glycol jacket, 1.5 mm outer wall

      Cone and body glycol jackets

      Proprietary TC lid cap with TC gasket retention system

      Lid cap includes combination 3" dry hop port and PRV

      Blow off tube and sanitary pressure gauge

      Zwickle sampling valve and analog thermometer

      1.5" TC rotatable racking arm with DIN nut, 1.5" lower dump port (2in on 3.5 bbl tank)

      Discrete cylinder and cone jackets allow for half batching

      1/2" NPT glycol inlet and outlet ports with internal jacket tie

      316 SS carbstone with valve

      Cone mounted sleeved RTD port with probe included

      4 MM lower stiffener plate with adjustable feet
